A data center designed with corporate clients in mind.
Located in North Central Florida. The Gainesville Data Center was built for security, high availability, connectivity and redundancy. Tenants benefit from an a high power-to-space ratio and local technicians who safeguard your IT assets and support the management of your computing systems. Our 2100 sq ft of state-of-the-art, ground-level floor space gives you the freedom and flexibility to scale seamlessly. Our nationwide private WAN service portfolio and associated geographically disperse data center space let’s you build a rock solid IT solution.
Security
- Multiple layers of security & authentication; including card key & PIN required for facility entrance
- Full CCTV surveillance backed by digital recording on file for 90 days
- Locking cabinets and/or cages
- Firewall management and monitoring services
- Wind roof rating FM-90
Power Infrastructure
- 1.2 MW of utility power
- 300 watts/sq ft
- 208v AC standard for increased efficiency
- All power delivered under raised floor
- Two (2) power distribution units delivering true A & B power supply
- A & B legs presented in-cabinet as separate power strips
- Complete American Power Conversion (APC) solution
- 250 KW backup diesel generator on standby
- Generator tested monthly and routinely full-load tested
Cooling
- Redundant HVAC with Liebert air handlers
- Cabinets laid out for optimum airflow – cold air at front base of cabinets
- Ambient temperature of 72 degrees
Equipment
- APC full and half cabinets
- APC cabling
- APC ladder rack
- APC monitored power strips
- APC environmental monitoring
- APC backup in-row HVAC
- Cisco switching environment
- Fiber and Copper Interconnects
Environment
- Single tenant, single-story building
- 12 inch raised floors
- 300 lbs/sq ft floor load
- Solid cabling routed neatly in overhead ladder rack
- Dry pipe fire suppression
- Integrated smoke/heat detector system
